No-Pegboard Three-Drawer Composite Workbench
The No-Pegboard Three-Drawer Composite Workbench, independently developed by Guang'ermei Precision Components, features a modular bolt-together structure and a high-load-capacity composite tabletop. It is designed for workshop environments that demand spatial flexibility and durability, such as electronics assembly, automotive parts inspection, and hardware mold maintenance.
Highlights
- Pegboard-free design provides an unobstructed view, facilitating equipment cable routing and daily cleaning
- 50mm composite tabletop is wear-resistant and oil-resistant, supporting loads up to 1000kg
- C-shaped 100×50mm cold-rolled steel frame delivers a total load capacity of 1000kg
- Three horizontally arranged drawers, each supporting up to 80kg, enable refined tool management
- Modular bolted connections allow for rapid installation and future structural adjustments
Specifications
- Standard Dimensions (L×W×H)
- 1500×750×800mm｜1800×750×800mm｜2100×750×800mm
- Tabletop Structure
- 2mm green wear-resistant laminate + 48mm high-density board + black PVC edge banding, 50mm total thickness
- Frame Material
- 1.5mm cold-rolled steel sheet, C-section 100×50mm
- Drawer Configuration
- 3 horizontal drawers, internal dimensions 320/420/520×430×115mm, single slide rail, 80kg load capacity per drawer
- Cabinet Panel
- 1.0mm bare steel sheet
- Surface Treatment
- Pickling & phosphating + electrostatic powder coating + 250℃ high-temperature baking
- Color
- Standard gray-white; other colors available upon request
- Packaging
- Knocked-down carton packaging (frame, drawers, and tabletop packed separately)
- Gross Weight Reference
- 1500mm model approx. 78.7kg｜1800mm model approx. 87.5kg｜2100mm model approx. 97.6kg
Streamlined Structure · Reliable Load Capacity · Easy Installation
The No-Pegboard Three-Drawer Composite Workbench is a classic model in Guang'ermei's "Composite Tabletop Workbench" series, specifically optimized to minimize visual obstruction, enhance operational visibility, and improve maintenance convenience. Eliminating the traditional pegboard structure, it adopts an overall C-frame bolted connection design for quick assembly and subsequent adjustments, adapting to the dynamic layout requirements of lean production environments.
Core Design Highlights
- Composite Tabletop System:Total thickness of 50mm, integrally hot-pressed from a 2mm green wear-resistant film + 48mm high-density board + black PVC edge banding, offering excellent wear resistance, oil stain resistance, and impact resistance, with a static load capacity of up to 1000kg;
- High-Rigidity Frame:C-section profile of 100×50mm, main body formed by bending and welding 1.5mm cold-rolled steel plate, with a rated load capacity of 1000kg for the entire unit, meeting the demands of heavy-duty tooling and multi-process parallel operations;
- Three-Drawer Horizontal Layout:3 independent drawers (height 115mm) with internal dimensions of 320/420/520×430mm respectively, equipped with stamped single-slide rails as standard, each drawer supporting up to 80kg, facilitating categorized tool storage and high-frequency access;
- Industrial-Grade Surface Treatment:Gray-white as the primary color, processed through acid pickling and phosphating + powder electrostatic spraying + 250°C high-temperature curing, delivering strong coating adhesion, corrosion resistance, and easy cleaning, compliant with 6S workplace management standards.
Specifications and Delivery Support
Standard in-stock specifications: 1500×750×800mm | 1800×750×800mm | 2100×750×800mm; custom sizes available upon request. The unit is packaged in separate cartons (frame, drawer assembly, and composite tabletop individually sealed) for convenient transportation and on-site assembly. Factory inspection reports and full logistics tracking services are supported.
