Beech Wood Workbench with Bench Vise
Custom-manufactured by Guang'ermei Precision Components, this beech wood workbench features a 50mm thick finger-jointed beech tabletop combined with a C-channel cold-rolled steel frame. Equipped with a standard 4-inch heavy-duty bench vise, it supports up to 1,000 kg and is designed for high-load applications such as fitter assembly, mechanical processing, and maintenance inspection.
Highlights
- 50mm thick finger-jointed beech tabletop — impact-resistant, high load capacity, low deformation
- C-channel cold-rolled steel frame with 250°C high-temperature powder coating for lasting durability
- Standard 4-inch heavy-duty bench vise (100mm jaw width, 120mm jaw opening)
- Modular bolted construction for quick on-site assembly and future expansion
- Suitable for electronic assembly, automotive parts repair, hardware & mold debugging, and more
Specifications
- Tabletop Material & Thickness
- Premium finger-jointed beech composite board, 50mm total thickness
- Tabletop Load Capacity
- ≥1,000 kg (static uniform distributed load)
- Frame Material & Process
- 1.5mm cold-rolled steel plate, C-channel structure; acid-washed, phosphated, and electrostatically powder-coated (250°C baking)
- Overall Load Capacity
- ≥1,000 kg
- Bench Vise Specifications
- 4-inch heavy-duty bench vise, 100mm jaw width, 120mm max jaw opening, net weight approx. 11 kg
- Standard Dimensions (L×W×H)
- 1500×750×800mm / 1800×750×800mm / 2100×750×800mm
- Packaging
- Knock-down carton packaging, including all connectors and assembly instructions
Heavy-Duty Beech Wood Workbench, Designed for Precision Clamping
The Beech Wood Workbench with Bench Vise series launched by Guang'ermei Precision Components combines the stability of solid wood with the reliability of metal structures, meeting the core manufacturing needs for workstation equipment: 'high load capacity, stable precision, and easy maintenance'. The tabletop is made of premium beech wood, composite-formed through finger-jointing technology, with a thickness of 50mm. The surface is flat and dense, offering impact resistance, wear resistance, and long-term deformation resistance.
Core Structural Advantages
- Reliable Load Capacity:The entire workbench has a rated load capacity of 1000kg, with the tabletop alone also supporting 1000kg, suitable for medium to high-intensity operations such as drilling, milling, riveting, and manual assembly;
- Stable Frame:The main body adopts a C-shaped frame bent from 1.5mm cold-rolled steel plate (cross-section 100×50mm), treated with pickling and phosphating plus electrostatic powder coating (cured at 250℃ high temperature), providing anti-corrosion, anti-rust properties, and strong structural rigidity;
- Professional Bench Vise Configuration:Equipped with a standard 4-inch (100mm jaw width) heavy-duty bench vise, with an actual opening of 120mm. It features strong self-locking capability and high repeat positioning accuracy, supporting left and right dual-direction installation for multi-angle workpiece clamping;
- Flexible Adaptability:Modular bolted connection structure supports quick on-site disassembly and assembly, as well as later functional expansion (such as adding pegboards, lighting, power interfaces, etc.).
Standard Specifications and Customization Support
Three standard sizes available in stock:
● 1500×750×800mm (gross weight approx. 60.5kg)
● 1800×750×800mm (gross weight approx. 70.6kg)
● 2100×750×800mm (gross weight approx. 78.2kg)
Non-standard customization supported: tabletop length/width/height adjustment, drawer/cabinet combination additions, bench vise quantity and position optimization, color (mainly gray-white, RAL color system optional), surface treatment process upgrades, etc., meeting 6S site management and production line layout requirements.
