Single Pegboard Three-Drawer Composite Workbench
A modular composite workbench independently developed by Guang'ermei Precision Components, featuring a high-density board and wear-resistant laminate composite desktop with a C-shaped cold-rolled steel frame. Standard configuration includes three drawers and a 500mm square-hole pegboard, balancing load capacity, expandability, and 6S workplace management compatibility. Available in multiple standard sizes with custom options.
Highlights
- 50mm total desktop thickness: 2mm wear-resistant laminate + 48mm high-density board, 1000kg load capacity
- C-shaped cold-rolled steel frame with 100×50mm cross-section, 1000kg overall load capacity
- Three-drawer layout (115mm height × 3), 80kg load per drawer, three selectable internal depth options
- Standard 500mm square-hole pegboard (10×10mm hole pitch), 10kg load per hole, louver panel interchangeable
- Bolted knock-down structure, pickling & phosphating + electrostatic powder coating, 250°C high-temperature curing
Specifications
- Standard Dimensions (L×W×H + Pegboard H)
- 1500×750×800+500mm | 1800×750×800+500mm | 2100×750×800+500mm
- Desktop Structure
- 2mm green wear-resistant laminate + 48mm high-density board + black PVC edge banding
- Frame Material & Specification
- 1.5mm cold-rolled steel plate, C-shaped structure, 100×50mm cross-section
- Drawer Configuration
- Three horizontal drawers, 115mm height; selectable internal depth
- Pegboard Specification
- 500mm high square-hole pegboard, 10×10mm hole pitch, 1.0mm cold-rolled plate; louver panel optional
- Surface Treatment
- Pickling & phosphating + electrostatic powder coating, 250°C high-temperature baking and curing
- Standard Color
- Gray-white (customizable on request)
- Packaging & Structure
- Bolted knock-down assembly, carton packaging
- Gross Weight Reference
- 1500mm model approx. 86.3kg | 1800mm model approx. 96.2kg | 2100mm model approx. 107.4kg
Guangermei Precision Components has been dedicated to the R&D and manufacturing of workshop workstation equipment for over a decade. ThisSingle Pegboard Three-Drawer Composite Workbenchis a classic configuration in the composite desktop series, widely used in electronic assembly, automotive parts inspection, hardware mold maintenance, and school training scenarios that have comprehensive requirements for operating space, tool storage, and visual management.
Core Design Advantages
Composite High-Strength Desktop:With a total thickness of 50mm, it is formed by hot-pressing a 2mm green wear-resistant film (oil-resistant and impact-resistant), a 48mm high-density board substrate, and black PVC edge banding. The desktop has a static load capacity of up to 1000kg, with a flat and wear-resistant surface that meets the demands of frequent operations and heavy workpiece placement.
Sturdy Load-Bearing Frame:The main body adopts a C-shaped frame formed by bending 1.5mm cold-rolled steel plates (cross-section 100×50mm). The overall structure is mechanically optimized, with a rated load capacity of 1000kg for the entire workbench, supporting long-term stable use.
Efficient Storage System:Three independent drawers are arranged horizontally (each with a height of 115mm), with internal depths available in three levels: 320mm / 420mm / 520mm. Equipped with stamped single guide rails, each drawer has a load capacity of 80kg. The cabinet body is made of 1.0mm bare plate, balancing strength and lightweight design.
Flexible Expansion Interfaces:The top integrates a 500mm high standard square-hole pegboard (hole spacing 10×10mm), with a single-hole load capacity of 10kg, allowing free mounting of hooks, shelves, tool racks, and other accessories. It can also be replaced with a louvered pegboard as needed to improve ventilation and visibility.
Process and Delivery Assurance
The entire series adopts a knock-down bolted connection structure, with pre-assembly calibration completed before shipment and standardized carton packaging for easy transportation and quick on-site installation. The surface treatment includes pickling and phosphating followed by powder electrostatic spraying, cured at a high temperature of 250°C, resulting in strong coating adhesion, corrosion resistance, and resistance to peeling. The standard color is gray-white, with custom colors available according to customer VI requirements.
Applicable Scenarios
- Electronics Manufacturing: SMT patch auxiliary operations, PCBA functional testing workstations
- Automotive Parts Plants: Small assembly, quality inspection and rework stations
- Hardware Mold Workshops: Fitter mold repair, measuring instrument temporary storage, and small fixture placement
- Vocational Colleges: Mechanical processing and mechatronics training platforms
- Maintenance and Testing Centers: Instrument calibration, wire harness organization, and tool return areas
