Single-Door 4-Drawer Cabinet Composite Workbench with Dual Pegboards
The Single-Door 4-Drawer Cabinet Composite Workbench, independently developed by Guang'ermei Precision Components, features a modular knock-down structure integrating dual-type pegboards (square hole + louver), an LED lighting frame, and a high-density composite tabletop. It is designed for workshop environments such as electronic assembly, automotive parts inspection, and mold repair, where space management and load-bearing performance are critical.
Highlights
- Composite Laminate Tabletop: 50mm thick, wear-resistant and oil-resistant, supports up to 1000kg
- Dual Pegboard Design: Square hole and louver combination, 10kg load capacity per hole, compatible with various hanging accessories
- 4-Drawer Tiered Storage: Mixed high and low drawer heights, aluminum alloy handles with label slots, compliant with 6S visual management
- Integrated LED Light Frame: Includes 16W lighting and power outlets, ready to use upon installation
Specifications
- Tabletop Structure
- 2mm green wear-resistant film + 48mm high-density board + black PVC edge banding, hot-pressed
- Frame Material
- 1.5mm cold-rolled steel, C-channel profile 100×50mm
- Drawer Configuration
- 4 drawers per cabinet (2×100mm high + 2×200mm high), stamped single rail, 80kg load capacity per drawer
- Pegboard Specifications
- 1 square hole pegboard (10×10mm hole spacing) and 1 louver pegboard, 450mm height, bare board thickness 1.0mm
- Light Frame System
- 1000mm height, includes 16W LED fluorescent lamp, combined 2-pin/3-pin power outlet, and matching power cord
- Surface Treatment
- Acid washing and phosphating + electrostatic powder coating, cured at 250℃ high temperature, standard gray-white
Product Overview
This Single-Door 4-Drawer Cabinet Composite Workbench is the flagship model in the Guang'ermi Precision Components Combination Cabinet series, specifically designed to enhance workstation space utilization and tool visual management. The entire unit adopts a C-type cold-rolled steel frame with a composite laminate tabletop structure, supporting flexible dual pegboard configuration, balancing functionality, durability, and 6S workplace management requirements.
Core Features
- Composite Tabletop System: Total thickness of 50mm, formed by hot pressing 2mm green wear-resistant film + 48mm high-density board + black PVC edge banding, offering excellent wear resistance, oil resistance, and impact resistance, with a static load capacity of 1000kg on the tabletop;
- Dual Pegboard Collaborative Management: Standard equipped with one 450mm high square-hole pegboard (10×10mm hole spacing) and one louvered pegboard, each hole supporting 10kg, accommodating diverse hanging accessories such as tools, measuring instruments, and cable clips;
- Modular Drawer Layout: Single cabinet configured with 4 drawers (2 x 100mm high + 2 x 200mm high), internal dimensions 460×460mm, featuring stamped single-rail structure, 80kg load capacity per drawer, aluminum alloy handle with label slot for easy classification and identification;
- Integrated Lighting Rack: Top-mounted 1000mm high lighting rack, including 16W LED fluorescent lamp, combined 2/3-hole power socket, and power cord, meeting basic workstation lighting and equipment power supply needs;
- Industrial-Grade Structural Craftsmanship: Frame made of 1.5mm cold-rolled steel plate (cross-section 100×50mm), cabinet body 1.0mm/panel 1.5mm cold-rolled plate, treated with pickling and phosphating + electrostatic powder coating (250℃ high-temperature curing), standard gray-white color with customization options available.
Specifications
| Item | Parameter Description |
|---|---|
| Overall Dimensions (L×W×H) | 1500×750×800+1000mm / 1800×750×800+1000mm / 2100×750×800+1000mm (including lighting rack) |
| Total Workbench Load Capacity | ≥1000kg (including tabletop, frame, and fully loaded drawers) |
| Cabinet Dimensions (W×D×H) | 566×600×700mm |
| Packaging Method | Knock-down structure, bolt-connected, carton packaging |
| Gross Weight Reference | 1500mm model approx. 135.7kg | 1800mm model approx. 146.7kg | 2100mm model approx. 162.2kg |
