Double Pegboard 3-Drawer Pull-Stop Iron Plate Workbench
The Double Pegboard 3-Drawer Pull-Stop Iron Plate Workbench, independently developed by Guang'ermei Precision Components, features a high-strength C-type frame and a composite iron plate tabletop, delivering superior load capacity, durability, and 6S workplace management compatibility. Ideal for demanding workstation environments such as electronic assembly, automotive component inspection, and hardware mold maintenance.
Highlights
- Composite Iron Plate Tabletop: 5mm iron plate + high-density base material + PVC edge banding, 1000kg load capacity, wear and impact resistant
- Dual Pegboard System: Square hole + louver dual modules, 10kg load per hole, compatible with 6S tool visual management
- 3 Drawers + Bottom Pull-Stop: 3-depth drawers + optional pull-stop structure, enhancing layered tool storage efficiency
- C-Type Heavy-Duty Frame: 1.5mm cold-rolled steel, 100×50mm cross-section, 1000kg rated load capacity for the entire bench
- Ready-to-Use Design: Full bolt connection, modular assembly and disassembly, supports factory inspection and on-site installation guidance
Specifications
- Standard Dimensions (L×W×H + Light Frame)
- 1500×750×800+1000mm | 1800×750×800+1000mm | 2100×750×800+1000mm
- Tabletop Structure
- 5mm cold-rolled iron plate + 45mm high-density board + black PVC strip, 50mm total thickness
- Frame Material & Load Capacity
- C-type cold-rolled steel plate (1.5mm thick, 100×50mm cross-section), 1000kg total load capacity
- Drawer Configuration
- 3 horizontal compartments, internal dimensions 320/420/520×430mm, single rail, 80kg load per drawer
- Pegboard Specifications
- 450mm high square hole pegboard (10×10mm hole spacing) + 1 louver pegboard, 10kg load per hole
- Light Frame System
- 1000mm height, includes LED fluorescent lamp (16W), 2/3-hole integrated socket, and power cord
- Surface Treatment
- Acid washing and phosphating + high-temperature powder electrostatic coating (250℃ baking), standard gray-white
- Packaging & Installation
- Detachable bolt connection, carton packaging, supports remote technical guidance or on-site installation service
Modular Iron Plate Workbench Designed for Heavy-Duty Workstations
The Double Pegboard 3-Drawer Pull-Stop Iron Plate Workbench is the flagship model in Guang'ermi Precision Components' 'Double Pegboard Series', integrating structural stability, tool storage efficiency, and on-site visual management requirements. The entire unit adopts a detachable bolted connection structure, supporting rapid deployment and flexible adjustment. It is widely used in electronic manufacturing production lines, automotive parts inspection areas, mold repair workstations, and training workshop classrooms.
Core Structural Advantages
- Composite Iron Plate Tabletop: 5mm native cold-rolled iron plate + 45mm high-density base material + black PVC edge banding, with a total thickness of 50mm. The surface is wear-resistant, high-temperature resistant, and impact-resistant, with a static load capacity of up to 1000kg;
- Heavy-Duty C-Frame: Cross-section of 100×50mm, integrally formed from 1.5mm cold-rolled steel plate. The entire table has a rated load capacity of 1000kg, meeting the requirements for placing large fixtures and inspection equipment;
- Dual-Function Pegboard System: Standard configuration includes one 450mm high square-hole pegboard (10×10mm hole spacing) and one louvered pegboard, with a single-hole load capacity of 10kg, supporting standardized hanging management of tools, gauges, cables, etc.;
- 3-Drawer + Pull-Stop Combined Storage: Three horizontal drawers (internal dimensions 320/420/520×430mm), equipped with stamped single rails, with a single drawer load capacity of 80kg; an optional pull-stop structure is set at the bottom to enhance cabinet stability and expand bottom storage space.
Flexible Configuration and Process Assurance
Standard specifications offer three sizes: 1500×755×800+1000mm, 1800×750×800+1000mm, and 2100×750×800+1000mm, available in stock; non-standard sizes support customization. Both the tabletop and frame undergo acid washing and phosphating pretreatment, followed by 250℃ high-temperature powder electrostatic spraying. The main color is gray-white, with industrial-grade custom color options available upon request. The gross weight of the entire machine is 143.2–188.1kg, packed in cartons, suitable for logistics transportation and on-site assembly.
