4-Drawer Tool Cart
The 4-Drawer Tool Cart, independently developed by Guang'ermei Precision Components, features a 1.0mm cabinet body with 1.5mm reinforced drawer panels and a dual-layer load-bearing design (2×100mm + 2×200mm drawers). Each drawer supports up to 80kg, meeting the 6S management and high-frequency retrieval needs in electronics, automotive, mold, and other manufacturing environments.
Highlights
- Dual-layer drawer configuration: 2 shallow + 2 deep drawers for tiered storage of various tools
- 1.5mm reinforced drawer panels + 1.0mm cabinet body for enhanced impact resistance and durability
- 80kg load capacity per drawer, suitable for long-term storage of heavy hand tools
- Gray-white cabinet with blue drawer panels for intuitive color-coded 6S visual management
Specifications
- Overall Dimensions
- 566 × 600 × 850 mm (W×D×H)
- Drawer Configuration
- 100mm height × 2, 200mm height × 2
- Load Capacity per Drawer
- ≤80kg (static evenly distributed load)
- Main Body Material
- Cabinet body
- Surface Treatment
- Gray-white + blue powder coating (customizable RAL color codes)
- Mobility System
- φ100mm dual-brake swivel casters × 4 (2 fixed + 2 swivel)
Professional-Grade 4-Drawer Tool Cart | Modular Design · High Load Capacity · Easy Mobility
Guang'ermei Precision Components has focused on the R&D and manufacturing of workshop workstation equipment for over a decade. This 4-drawer tool cart is specifically optimized for frontline manufacturing operations, balancing structural strength, operational convenience, and space utilization. It is widely used in electronic assembly lines, automotive parts repair stations, hardware and mold workshops, and training environments.
Core Design Advantages
- Clear Layered Storage Logic: Equipped with 2 shallow drawers at 100mm height (for storing screws, retaining rings, small parts, and other small items) + 2 deep drawers at 200mm height (for carrying wrenches, sockets, measuring tools, and other medium-to-large tools), preventing mixed storage and improving retrieval efficiency;
- Reliable Slide Rail System: All drawers come standard with stamped single-rail slides, tested for tens of thousands of push-pull cycles, ensuring smooth operation without jamming and supporting stable extension under full load;
- Reinforced Structure for Durability: The main cabinet body is made of 1.0mm high-quality cold-rolled steel, with drawer front panels thickened to 1.5mm, effectively preventing deformation or impact dents caused by long-term use;
- Ergonomic Adaptation: Overall dimensions are 566×600×850mm (W×D×H), conforming to standard workstation height workflow. The bottom is equipped with 4 φ100mm dual-brake swivel casters (2 fixed + 2 swivel), ensuring flexible mobility and stable positioning.
Basic Parameters and Configuration
| Item | Parameter Description |
|---|---|
| Overall Dimensions | 566mm (W) × 600mm (D) × 850mm (H) |
| Drawer Specifications | 100mm height × 2 + 200mm height × 2 |
| Load Capacity per Drawer | ≤80kg (static evenly distributed load) |
| Main Material | Cabinet: 1.0mm cold-rolled steel; Drawer panels: 1.5mm cold-rolled steel |
| Surface Treatment | Cabinet: gray-white powder coating; Drawer panels: blue powder coating (RAL color series available upon request) |
| Mobility System | 4 φ100mm dual-brake swivel casters (including 2 fixed casters to ensure straight-line pushing stability) |
Extended Application Scenarios
In addition to the standard configuration, this series supports on-demand expansion: optional pegboard systems (compatible with standard hooks/tool racks), anti-static coatings (suitable for ESD-sensitive areas), internal drawer dividers (ABS/metal adjustable partitions), reserved nameplate identification areas, and other non-standard customization services to meet different production lines' requirements for tool visualization, fixed-position management, and error-proofing management.
