4-Drawer 1-Door Tool Cart with Pegboard
The 4-Drawer 1-Door Tool Cart with Pegboard, independently developed by Guang'ermei Precision Components, is engineered for on-site tool storage and efficient retrieval in manufacturing environments. It integrates drawer-based storage, a modular pegboard, and a unified cabinet door structure, balancing load capacity, flexibility, and 6S visual management requirements.
Highlights
- 4-drawer tiered design for organized storage and retrieval of tools in various sizes
- 500 mm standard square-hole pegboard for flexible expansion and visual management
- 80 kg load capacity per drawer with stable overall structure and smooth operation
- Gray-white electrostatic powder coating for wear resistance, easy cleaning, and workshop compliance
Specifications
- Overall Dimensions (W × D × H)
- 1000 × 500 × 850 mm (including 500 mm pegboard height)
- Material Specification
- Cabinet Body
- Drawer Configuration
- 100 mm H × 2 + 200 mm H × 2; stamped single rail, 80 kg per drawer
- Pegboard Specifications
- 500 mm high square-hole pegboard, 10 × 10 mm hole spacing, 15 kg load per hole
- Color
- Gray-white electrostatic powder coating
- Gross Weight
- Approx. 61.5 kg
Multi-functional Mobile Tool Cart for Lean Production
This tool cart is a workstation mobile solution deeply optimized by Guang'ErMei for scenarios such as electronic assembly, automotive repair, and hardware mold workshops. It adopts a cold-rolled steel plate one-piece molding process, with a stable and reliable main structure, supporting frequent relocation and long-term high-load use.
Core Functional Design
- Four-tier Differentiated Drawer Layout: Equipped with 2 shallow drawers of 100mm height (suitable for small measuring tools and screwdriver sets) + 2 deep drawers of 200mm height (capable of carrying wrenches, sockets, pneumatic tools, and other medium-to-large tools), each drawer can bear up to 80kg, equipped with stamped single rails for smooth sliding and precise return;
- 500mm Height Standard Square Hole Pegboard: 10×10mm uniform hole spacing, single hole load capacity of 15kg, compatible with universal hooks, tool racks, and custom accessories, achieving 'what you see is what you get' visual hanging management of tools;
- Integrated Cabinet Door Protective Structure: A single swing cabinet door is set on the top, effectively shielding the upper space, preventing dust intrusion or small items from falling, and improving on-site cleanliness and safety;
- Industrial-grade Materials and Surface Treatment: The cabinet body is made of 1.0mm cold-rolled steel plate, and the drawer panels are thickened to 1.5mm; the overall gray-white electrostatic powder coating is scratch-resistant and wear-resistant, meeting the anti-corrosion and anti-rust requirements of the workshop environment.
Adaptable to Various Manufacturing Scenarios
Suitable for scenarios such as quick response workstations beside production lines, mobile equipment maintenance workstations, temporary mold debugging operation tables, and tool circulation areas for practical training and teaching. It can be seamlessly integrated with Guang'ErMei workbenches and lean tube tooling systems, helping enterprises promote 6S standardization and the integrated upgrade of workstation equipment.
